21.2inch Android Bar Display: High-Definition Smart Signage with USB Ad Screen
BR21XCB-N Advertising Screen Overview
This device features a 21.2-inch high-definition liquid crystal display with a resolution of 1920x360 pixels and brightness of 500 cd/m². It uses an WLED backlight source and has a lifespan of 30,000 hours. The contrast ratio is 1200:1 and it supports a frame rate of 60 Hz. The color depth is 16.7M , 72% NTSC.
The system runs on Rockchip PX30 Quad core ARM Cotex-A35 processor clocked at 1.5GHz and comes with 1GB DDR3 RAM (selectable between 1GB/2GB) and 8GB built-in storage (selectable between 8GB/16GB/32GB/64GB). It supports external storage up to 64GB TF card. It supports wireless network connectivity via Wi-Fi and Bluetooth V4.0. The interface includes 1 micro USB (OTG), 1 SD card, and 1 Type-c (DC 12V power supply). The operating system is Android 8.1.
The power consumption is ≤21W and the voltage is DC 12V. The net weight of the device is less than 2.1kg.
The working environment temperature should be between 0°C~50°C with humidity ranging from 10%~85%. Storage environment temperature should be between -20°C~60°C with humidity ranging from 5%~95%.
The device meets CE and FCC certification standards and comes with a warranty of 1 year. Accessories include adapters and wall mounting plate.
Product feature
- LCD HD display
- Support 7*24 hours work
- Single player
- The APK starts automatically
Product Parameter(Model: BR21XCB-N)
| TFT Screen | Size | 21.2" |
| Display area | 532.7(H)X104.6(V)mm | |
| Resolution | 1920(V)x360(H) | |
| Brightness | 500 cd/㎡ | |
| Backlight source | WLED | |
| Lifespan | 30000 hours | |
| Viewable angle | 89/89/89/89 (Typ.)(CR≥10) | |
| Contrast ratio | 1200:1 | |
| Frame rate | 60 Hz | |
| Color depth | 16.7M , 72% NTSC | |
| Response time | 30ms | |
| System | Processor | Rockchip PX30 Quad core ARM Cotex-A35 |
| Memory | 1GB | |
| Built-in storage | 8GB (8GB/16GB/32GB/64GB selectable) | |
| External storage | Max supports 64GB TF card | |
| Network/BT | Supports 2.4G wireless network WiFi, Bluetooth V4.0 connectivity | |
| Interface | 1 micro USB (OTG), 1 SD card, 1 Type-c (DC 12V power supply) | |
| Operating System | Android 8.1 | |
| Power supply | Power | ≤21W |
| Voltage | DC 12V | |
| Whole machine and packaging | Size | 549.7*124.6*26mm |
| Net weight | ≤2.1 kg | |
| Package size | TBA | |
| Gross weight | TBA | |
| Environment | Working environment | Temperature: 0°C~50°C Humidity: 10%~85% Pressure: 86kPa~104kPa |
| Storage environment | Temperature: -20°C~60°C Humidity: 5%~95% Pressure: 86kPa~104kPa | |
| Certification | CE, FCC certification | Available |
| Accessories | Warranty | 1 year |
| Accessories | Adapters, wall mounting plate | |
| Other options | OTG cable |
Featured collection
Product description display
BOE offers premium display solutions, including bar-shaped, high-brightness, embedded, square displays, and commercial products to fulfill diverse needs. BOE is your all-in-one solution for indoor and outdoor displays.
Product feature introduction
UHD
Ultra HD display
Feature name
Simultaneous multiple display with composite playback function
You can create composite content consisting of videos plus multiple static images or dynamic images using pre-installed software.
FAQ
Questions about TFT LCD screens
Are your TFT LCD Displays compliant with RoHS and Reach standards?
Yes, the TFT LCD Displays are compliant with both RoHS and Reach standards.
Can the longevity of the TFT LCD Displays be assured?
- Yes, our TFT LCD Displays are designed and tested for longevity, providing reliable performance over a long period.
What technical support do you provide after purchase?
- After the purchase, our technical team offers continuous support to troubleshoot any issues and ensure optimal performance of our TFT LCD Displays.
Can I return or exchange a TFT LCD Display if it is defective or doesn't meet my needs?
- Absolutely! We have a customer-friendly return and exchange policy in place for defective products or those that do not meet your expectations.
How can I get in touch with your support team if I face any issues with the TFT LCD Display?
- Our support team is available round-the-clock. You can contact us via email, phone, or fill out the support form on our website. We aim to respond to all inquiries within 24 hours.
